E-zone® Cyclone Resistant Glass offers all the protection and peace of mind as StormShield®, with the added benefit of moderating Solar Heat Gain.
The pyrolitic process used in the manufacture of E-zone cyclone resistant glass embeds invisible heat-reflective materials into the glass. This allows light to enter, but reflects much of the inbound heat, increasing comfort. Conversely in cool climates we can configure E-zone to maximize heat retention.
Hydrostatic pressure testing has demonstrated that E-zone can provide substantially superior flood resistance when installed in a certified flood resistant frame compared to standard laminates.
Product Details
- Product
- E-zone | Cyclone Resistant Glass
- Category
- Safety Glass
- Sold by
- Glasshape
- Range
- Storm Glass
- Designer
- Glasshape
- Brand
- Glasshape
Product Variants
- Material
Glasshape is specified by
Sheppard & Rout ArchitectsArchitects
Hamish Shaw ArchitectsArchitects
BuchanArchitects
Bull O'Sullivan ArchitectureArchitects
Metro Performance GlassManufacturers and Suppliers
The Building AgencyManufacturers and Suppliers
CueskoQuantity Surveyors
Woods GlassManufacturers and Suppliers
TM Consultants LtdStructural Engineers
Glass By DesignManufacturers and Suppliers
E-zone® Cyclone Resistant Glass offers all the protection and peace of mind as StormShield®, with the added benefit of moderating Solar Heat Gain.
The pyrolitic process used in the manufacture of E-zone cyclone resistant glass embeds invisible heat-reflective materials into the glass. This allows light to enter, but reflects much of the inbound heat, increasing comfort. Conversely in cool climates we can configure E-zone to maximize heat retention.
Hydrostatic pressure testing has demonstrated that E-zone can provide substantially superior flood resistance when installed in a certified flood resistant frame compared to standard laminates.
- Specs
E-zone Glass Features & Benefits
- Decreased solar heat gain provides a cooler environment for improved working conditions and comfort
- Retains high levels of visual light transmission
- Reduce HVAC requirements and subsequent positive impact on systems size requirements
- ‘Always on’ – no taking temporary covers on and off
- Superior building aesthetics and unobstructed visibility
- Larger windows can be designed
- Withstands extreme pressure >12kPa, wind gusts >500 km/h
- Expedited recovery post-event
- Evaluated at the world class James Cook University cyclone testing station with excellent results
- Standard dimensions up to 3900mm x 2440mm
- 2D curves (single radius and single axis)
- AS/NZS 1170.2:2011
- AS/NZS 1288
- Certified in wide range of commonly available cyclone rated framing systems including Alspec, Capral, Alutech, AWS and Wintec
NB: Debris Impact Resistant certified framing system required
- Scope of use
Glasshape has recently improved its E-zone Glass product range and we are now offering combined product solutions for both Region C&D, E-zone Glass Ultra & E-zone Glass Extreme. These two new product variants provide multifaceted enhancements to combat the conditions experienced in both regions, E-zone Glass Ultra for impact resistance up to 39m/s & E-zone Glass Extreme for impacts up to 44m/s. E-zone Glass products are the only available annealed laminated product solution for Cyclone Resistance that can be cut and processed from stock sheets and available from our local stockists.
