Seguin Visio 8 Plus Cheminee Fireplace - Swing Door

by Sculpt Fireplace Collection

Sale, Australia

Sculpt Fireplace Collection logo
  • 711.9K profile views
  • 173 saves
Visit Website

You’ll never yearn again for complete harmony in your interior space once attaining the Seguin Visio 8 Plus Cheminee Fireplace with black glass and swing door. Made in Randan, France, and constructed with pure cast iron, this classic firebox with a contemporary black line printed glass, equipped with the Seguin air wash system that keeps the glass clean, you’ll be wanting to stay next to your new Seguin Visio 8 Plus Cheminee Fireplace all winter long.

Based in the heart of Auvergne, France, Seguin Duteriez fireplaces have been renowned for producing some of Europes most revolutionary and sought-after range of elite fireplace products for over 30 years. Artisan engineered and with the use of exclusive materials, Seguin fireplaces are manufactured with 100% pure cast iron and are highly regarding for their durability and increased heating output.

DAFS (Double Air Flow System):

The majority of Seguin wood fireplaces are equipped with DAFS technology with the aim to inject oxygen at a determined level inside the combustion chamber. The supply of new oxygen will burn the gases and smoke that has not yet been burnt and prevent them from being released into the flue system. The advantages of this; a longer fire term, cleaner glass, also total combustion of the firewood.

With an average cast iron thickness of 10mm (compared to others that are 4-6mm), these cast iron cheminee fireplaces are well known for their heat retention even after the fire has dissipated, allowing for a longer-lasting heat well into those colder nights. All Seguin cast iron fireboxes come with a damper, air wash system, fire grate, and ash pan as standard, and thanks to the choice of high-quality raw material Seguin cast iron cheminee fireboxes are guaranteed for 10 years.

Product Details

Product
Seguin Visio 8 Plus Cheminee Fireplace - Swing Door
Brand
Seguin
Year
2015
Warranty
10 years

Product Variants

Colours
Material
Size

Product specified by

Seguin Visio 8 Plus Cheminee Fireplace - Swing Door
Visit site

You’ll never yearn again for complete harmony in your interior space once attaining the Seguin Visio 8 Plus Cheminee Fireplace with black glass and swing door.

Made in Randan, France, and constructed with pure cast iron, this classic firebox with a contemporary black line printed glass, equipped with the Seguin air wash system that keeps the glass clean, you’ll be wanting to stay next to your new Seguin Visio 8 Plus Cheminee Fireplace all winter long.

Based in the heart of Auvergne, France, Seguin Duteriez fireplaces have been renowned for producing some of Europes most revolutionary and sought-after range of elite fireplace products for over 30 years. Artisan engineered and with the use of exclusive materials, Seguin fireplaces are manufactured with 100% pure cast iron and are highly regarding for their durability and increased heating output.

DAFS (Double Air Flow System):

The majority of Seguin wood fireplaces are equipped with DAFS technology with the aim to inject oxygen at a determined level inside the combustion chamber. The supply of new oxygen will burn the gases and smoke that has not yet been burnt and prevent them from being released into the flue system. The advantages of this; a longer fire term, cleaner glass, also total combustion of the firewood.

With an average cast iron thickness of 10mm (compared to others that are 4-6mm), these cast iron cheminee fireplaces are well known for their heat retention even after the fire has dissipated, allowing for a longer-lasting heat well into those colder nights. All Seguin cast iron fireboxes come with a damper, air wash system, fire grate, and ash pan as standard, and thanks to the choice of high-quality raw material Seguin cast iron cheminee fireboxes are guaranteed for 10 years.

Specs

Material:
100% pure cast iron firebox with internal refractory ceramic lining and glass door

kW Output:
27.8kW

Heating capacity (m2):
240-340m2*

Facade:
Clean frameless design (no trim)

Glassdoor:
Secure swing door with a black line printed edging around the glass

Minimum flue height:
4.5m

Flue dimensions:
200mm, 250mm, 300mm

Includes hot air transfer kit:
A duct and a register

Hearth dimension:
Minimum 500mm in front of any part of the fireplace, 250mm on either side and 75mm thick

Outside air kit:
Recommended for well-insulated homes

Warranty:
10-year firebox warranty*

Weight:
190kg

*Heating capacity (when used as a slow combustion heater) is based on 2.4m ceiling heights and 6-star rated homes. Factors such as building characteristics, quality of insulation, type of firewood used, and climatic zone will also affect the heating output. *In accordance with Australia and New Zealand Standard AS/NZS 2918:2001 *All product pictures are a guide only, all wood fires must be installed as per AS/NZS 2918:2001 *E&OE. See T’s & C’s

Performance

Seguin fireboxes are guaranteed for 10 years. This excludes the ash pan, bricks and fire grate retainers which are guaranteed for 1 year.

The warranty becomes effective at the date of purchase.
