QIKPAC CARRY

Technical Specifications

• Battery Capacity: 240Wh (equivalent to 66,780mAh)
• Usable Capacity: 200Wh
• Output Voltage: 21.0V – 29.4V

Safety Standards

• IEC/UL 62368-1 (Safety)
• IEC/UL 62133-2 (Li-ion Safety)
• EN/IEC 61000-6-3 & 61000-6-1 (EMC)
• FCC 15B (USA-EMC)
• UN38.3 (Shipping)

Additional Specifications

• Weight: 1.3kg
• Operation Temperature: 10 – 35°C
• Charging Range: 5°C to 45°C
• Discharging Range: 20°C to 60°C

Storage Temperature

• Up to 3 months: Store between -20°C and 40°C
• Longer duration: Between 10°C to 20°C (ideal)
  QIKPAC should be stored at 40-60% charge (2 LEDs) in a low humidity environment (less than 70% RH) with no corrosive gases and no condensation on cells and charged yearly to keep them at this level.

Estimated Performance

• Charge Cycles: 1,500 (with 70% capacity remaining, dependent on type of load and use)
• Estimated Lifespan: 5+ years

Charging Times (Hours)

• 1-2 Batteries: 5 – 8 hours
• 3 Batteries: 8 – 11 hours

Construction

• High-strength fire-retardant polycarbonate

Colours

• Black or white

Power Cord Options

• GST08 male to female interconnect cable

Installation

• Please contact OE Elsafe

Quality and Testing

• All QIKPAC battery units are manufactured using ISO9001 quality-controlled components and practices and are 100% tested before dispatch.

CE Marking - QIKPAC Battery is CE marked by OE Electrics as complying with:

• Electromagnetic Compatibility Directive 2014/30/EU
• Low Voltage Equipment Directive 2014/35/EU
• ROHS3 Directive EU 2015/863
• EU Batteries Directive 2013/56/EU
• Input Voltage: 30.0V (maximum)
• Maximum Output Current Per Port: 6A
• Total Shared Maximum Output Current: 12A

• UF-R for QIKPAC CARRY comes with an A+C or a C+C port, offering two power levels:

• TUF-R HP (A+C) 72W powers a single laptop and a smartphone or tablet.

• TUF-R CC (C+C) 150W powers two laptops simultaneously or one laptop and a smartphone or tablet.

• QIKPAC CARRY is modular by design to enable the upgrade or replacement of any parts, significantly extending the life of the product.  .

• QIKPAC CARRY is part of the ANIMATE solution. Cleverly designed as a modular system, ANIMATE is adaptable and equally at home integrated into commercial furniture, docked to a workstation, or as a portable power bank. Take a closer look at the full ANIMATE solution.
