Complete Plus Cavity Sliding Doors
Prestons, Australia
- 54.1K profile views
- 11 saves
D4 Doors Complete Plus Dual-mode Series range cavity units are designed for standard size doors on 90mm stud size with some sweet touches such as aluminium frames and cavity brush-seal. Includes soft-close & open mechanism and self-balancing roller wheels.
When designing the Complete Series units, we asked ourselves, why not offer more ‘premium’ features at an exceptionally affordable prices?
In addition to the standard features of the Complete Range cavity sliders, we’ve included extras like cavity brushes, aluminium split jambs, posts, and bottom plates with concealed guides.
The X-Wide Factor features robust aluminium centre mullions that reinforce the entire structure, making them ideal for doors wider than 920mm. This added rigidity gives designers, builders, and homeowners greater freedom to choose diverse wall finishes—think elegant wall tiles, rich marble, statement feature walls, and beyond…
Product Details
- Product
- Complete Plus Cavity Sliding Doors
- Category
- Cavity Slider Doors
- Sold by
- D4 Doors Sliding Systems
- Range
- Slide Easy
- Brand
- D4 Doors
D4 Doors Complete Plus Dual-mode Series range cavity units are designed for standard size doors on 90mm stud size with some sweet touches such as aluminium frames and cavity brush-seal.
Includes soft-close & open mechanism and self-balancing roller wheels.
When designing the Complete Series units, we asked ourselves, why not offer more ‘premium’ features at an exceptionally affordable prices?
In addition to the standard features of the Complete Range cavity sliders, we’ve included extras like cavity brushes, aluminium split jambs, posts, and bottom plates with concealed guides.
The X-Wide Factor features robust aluminium centre mullions that reinforce the entire structure, making them ideal for doors wider than 920mm. This added rigidity gives designers, builders, and homeowners greater freedom to choose diverse wall finishes—think elegant wall tiles, rich marble, statement feature walls, and beyond…
- Specs
- Max. Door Height: 2700mm
- Max. Door Width: 920mm (Std) / 1500mm (X-Wide Centre Mullion)
- Max. Door weight: 120kgs, Soft close supports up to 80kgs door weight.
- Max. Door Thickness: 27-40mm
- Type of Doors: Timber
- Plasterboard Thickness: 10mm (Std) / 13mm (Opt)
Custom order
MAX 2700H X 1500W, 90MM STUD
Please download the editable custom order form, or contact us to find out how our products can be tailored to your projects.
Jamb finish options
- Flush-Jamb, Flush-Pull convertible;
- Architrave
- P50 Shadow-line
- P25 Stopping angle
- Squre-Set (ATLAS Upgrade)
Materials
- Double wall design powder-coated aluminium track.
- LVL nogs & aluminium post and robust aluminium centre mullions.
- White primed F/J pine split reveals backed by triple wall aluminium jambs with cavity brush.
- Features
- Timer pelmets;
- Self-balancing roller wheels;
- Robust spring actioned quick-release plates;
- Split-jambs to suite 10mm Plasterboard. Optioned up-to 13mm;
- Soft-close both directions to suit doors up to 80kgs;
- Smart Jamb Spacers;
- Splayed Guides, ‘T’-Shape Nylon Guides;
- Concealed floor guide;
- Closing Jamb excluded.
- Scope of use
D4 Doors Complete Plus cavity sliders feature double wall ultra strong aluminium tracks and jump-proof, self-balancing roller wheels that adapt to any door deformation, ensuring lasting performance and peace of mind. One motion quick release plate helps fast door hung. With a soft-close and open mechanism, these sliders provide smooth, quiet gliding for a disturbance-free experience in the both residential and commercial projects. Smart Jamb-Spreaders are included to reduce impacts to the units during construction.
This is a great option for projects that favoured a ‘premium’ feel without the ‘premium’ price tag.
- Meet the Slide Easy Collection
Our exclusive collection of cavity sliding doors offers a refined selection of premium products crafted to elevate any interior. Combining elegance with discretion, these units integrate seamlessly into your space, maximizing functionality without sacrificing aesthetic appeal. Each design is meticulously engineered to provide both style and practicality, making them the ideal solution for sophisticated, space-saving interiors.
