UniCote® Coastal

By INSPIRE
Website

For That Extra Protection

UniCote® Coastal takes our standard zinc/aluminium alloy-coated steel substrate to the next level with the addition of magnesium. This enables the zinc to ‘flow’, which seals the cut edges, preventing exposure to premature corrosion. With a substantial 210gms/m2 coating this makes it ideal for harsher environments and those nearer the coast.

UniCote® Coastal is a highly durable product with improved cut edge performance designed to give excellent colour retention and high formability at moderate cost.

Details
  • Category
    Steel Roofing, Metal Cladding, Sectional Garage Doors
  • Range
    UniCote
  • Warranty
    30 years
Performance

UniCote® Coastal performance testing

SCRATCH RESISTANCE

Good scratch resistance. Testing includes needle scratch test – no marking of paint surface when a needle with a 2kg weight attached is drawn across. ASTM D5178-13.

IMPACT RESISTANCE

AS/NZS2728:2013 Table 2.2 and Appendix E. No loss of paint adhesion after a test piece is struck on the reverse side with a specified force, in line with the test methodology described in Appendix E.

BEND TEST

AS/NZS2728:2013 section 2.6.1 and Appendix F – No loss of adhesion or paint cracking when bent around a diameter equal to five times the thickness of the sheet.

FIRE RESISTANCE

Suitable for continuous service up to 100ºC. Continuous service at higher temperatures may cause some colour change and damage to the paint film.

SALT SPRAY

Meets the requirements of AS/NZS2728:2013 Sections 2.8 and 2.10.

HUMIDITY RESISTANCE

Meets the requirements of AS/NZS2728:2013 Sections 2.8 and 2.9.

QUV RESISTANCE (DURABILITY OF COATING SYSTEM)

Meets the requirements of AS/NZS2728:2013 Section 2.8 and Table 2.4. Note: Tests are conducted on a flat panel.

Warranty

A steel roof is most susceptible to the elements along cut edges – but not UniCote® Coastal. The addition of magnesium to the standard zinc/aluminium alloy makes all the difference. As time goes on it allows the protective metal coating to microscopically flow over the cut edge. At this point a sacrificial anti-corrosive reaction takes place and a robust seal is created.

Warranty Form

Technical Info

For those who like the finer details

TECHNICAL – Conforms to AS/NZS2728:2013. Suitable for ISO9223:2012. Atmospheric Classifications C1 – C4.

SUBSTRATE  – Hot-dipped zinc/aluminium/magnesium alloy coated steel coil, 210gms/m2 coating weight.

PRE-TREATMENT – Corrosion resistant chromate conversion coating.

PRIMER – Flexible corrosion resistant chromated primer. Nominal film thickness 7μ ± 1μ on the top side and 5μ ± 1μ on the reverse.

FINISH COAT – Flexible exterior acrylic, polyester or modified polyester coating. Nominal film thickness 18μ ± 2μ.

BACKING COAT – Shadow Grey (standard colour) wash coat, 5μ ± 1μ nominal thickness.

GLOSS – Typical gloss levels are 25 ± 5% measured in accordance with AS/NZS 1580.602.2 (60 degrees). A range of our colours can also be supplied in a low gloss version if required.

STRIPPABLE FILM –Products can be supplied with an optional strippable protective film at extra cost. This material has a relatively short life span when exposed to sunlight and weather. It should be removed either just before, or immediately after installation.

SKU: MagnaFlow Hamptons White
