PVE30 Single Passenger Elevator

By Vacuum Elevators NZ
Visit Website

The pneumatic vacuum elevator PVE30 model is one of the world’s smallest residential home lifts with an outer diameter of only 75 cm. It is safe to say that there are very few households that do not have the space to install this small home elevator.

The pneumatic vacuum elevator PVE30 accommodates one person ( 159 kg) and is available in two, three and four stops (max. height 10.5m ).

Like other lift models of vacuum elevators the PVE30 is installed right on the existing floor. Our vacuum elevators do not need a pit or machine room.

The pneumatic vacuum elevator PVE30 is the perfect choice for single-family existing homes and townhouses, to be installed quickly and practically without construction works.

The pneumatic vacuum elevator, being a lift that runs on air , greatly reduces energy costs and maintenance, since no pulleys, cables, or pistons are used. This air driven residential elevator consumes minimal energy during ascent and zero during descent, also making it an ecofriendly elevator.

Made of aluminum and polycarbonate, the pneumatic vacuum elevator PVE combines functionality with an elegant design, being a transparent panoramic lift which allows 360 ° visibility inside the house.

Details
  • Category
    Lifts & Elevators
  • Brand
    Pneumatic Vacuum Elevators LLC
  • Warranty
    5 years
General
  • Country of origin
    United States of America
  • Type of use
    Residential
  • Installation
    Professional installation required
Specifications

Technical Specifications

  • Two to five stops
  • Colors: White, Gray Navy, Black, Taupe and Light Gray.
  • Power Supply: 230 VAC – 50 Hz 3.0 KW
  • Size:
    a) External cylinder diameter: 750mm
    b) Internal Cabin diameter: 633mm
    c) Internal cabin height: 2005mm
  • Total Weight: 254kg for 3000mm ceiling
  • Lift Capacity: Standard model can carry up to 159Kg – (1 person)
  • Velocity: 0.15 m/sec
  • Inside the car
    LED lights
    Fan
    Phone (optional)
  • Electrical Circuits: 24 V.
  • Lubrication: Not required
  • Installation: No excavation or shaft required. Elevator rests on floor. Self supported.
  • Safety: Pressure switch; on free fall elevator brakes within (50.8mm); on electricity cut elevator automatically descends to ground floor; alarm system in cabin; emergency ventilation; door safety switches; telephone (optional).
