PVE37 Two Passenger Elevator

By Vacuum Elevators NZ
Visit Website

The pneumatic vacuum elevator  PVE37 model is the flagship product of PVE with over 6.000 units installed worldwide. The  PVE37 model is an ideal homelift for detached houses, townhouses and duplexes.

The pneumatic vacuum elevator  PVE37 has an outer diameter of 93.3 cm and can accommodate two people (205 kg). This homelift is available in two, three and four stops (max. height 10.5m).

Like other lift models of vacuum elevators the  PVE37 is installed on the existing floor and does not require a machine room, shaft, or pit, making it a clean, quick and easy installation.

Since the vacuum elevator is primarily operated using air, it greatly reduces energy costs and maintenance, since no pulleys, cables , pistons are used. This two passenger homelift consumes minimal energy during ascent and zero during descent, making the pneumatic vacuum elevator an ecofriendly elevator.

The pneumatic vacuum elevator is made of aluminum and transparent polycarbonate high strength, combining functionality with elegant design, being a transparent panoramic lift which allows 360 ° visibility inside the house.

Details
  • Category
    Lifts & Elevators
  • Brand
    Pneumatic Vacuum Elevators LLC
  • Warranty
    5 years
General
  • Country of origin
    United States of America
  • Type of use
    Residential
  • Installation
    Professional installation required
Specifications

Technical Specifications

  • Two to five stops
  • Colors: White, Gray Navy, Black, Taupe and Light Gray.
  • Power Supply: 230 VAC – 50 Hz 5.0 KW
  • Size:
    a) External cylinder diameter: 933mm
    b) Internal Cabin diameter: 820mm
    c) Internal cabin height: 1950mm
  • Total Weight: 350kg for 3000mm ceiling
  • Lift Capacity: Standard model can carry up to 205Kg – (2 persons)
  • Velocity: 0.15 m/sec
  • Inside the car
    LED lights
    Fan
    Phone
  • Electrical Circuits: 24 V.
  • Lubrication: Not required
  • Installation: No excavation or shaft required. Elevator rests on floor. Self supported.
  • Safety: Pressure switch; on free fall elevator brakes within (50.8mm); on electricity cut elevator automatically descends to ground floor; alarm system in cabin; emergency ventilation; door safety switches; telephone (optional).
Vacuum Elevators NZ
Visit Website

More from
Vacuum Elevators NZ

PVE52 Three Passenger Elevator (Wheelchair Accessible)
PVE52 Three Passenger Elevator (Wheelchair Accessible)
By Vacuum Elevators NZ
PVE30 Single Passenger Elevator
PVE30 Single Passenger Elevator
By Vacuum Elevators NZ

About the
Seller

Pneumatic Vacuum Elevators LLC are the designers and manufacturers of the only vacuum elevators in the world. PVE is an innovative, technology driven company that is revolutionising how people and goods are transported vertically. Started in 2002 in Miami, Florida, PVE is proudly manufacturing three different models of vacuum lifts, ranging from single passenger to a three passenger, wheelchair-accessible model.

Vacuum Elevators NZ Ltd. is the authorised distributor of Pneumatic Vacuum Elevators LLC in New Zealand. We offer a comprehensive suite of services for a seamless and worry-free experience. Our team ensures that our lifts provide a smooth and aesthetically pleasing installation, enhancing the overall appeal of your property.

Pneumatic Vacuum Elevators are available on every continent and now also in NZ to provide a clever and fashionable solution for vertical transportation in residential houses and luxury yachts.
