Edgetec® Double Disc Glass Balustrade
by Juralco
Invercargill, New Zealand
- 743.5K profile views
- 92 saves
Juralco Edgetec® Double Disc Glass Balustrade Anchor is a traditional stainless steel anchor fixing offering from the Edgetec balustrade range - ideal for those seeking a minimalist Frameless Glass Balustrade aesthetic. Double Disc Anchors are manufactured from solid 316 Marine Grade Stainless Steel. The 30mm long body sets the 12mm - 17.52mm toughened glass panels out from the deck to assist with water draining and cleaning.
The Double Disc Anchor system is ideal for external balconies and stairs - as well as for internal stairs and landings. It can be fixed directly to either timber, steel or concrete surfaces and is finished with a 38mm x 30mm interlinking top rail in a choice of powder coat colours to suit. The finish options are mirror-polished stainless steel with a hidden fixing detail or satin stainless steel with a visible fixing detail.
The latest product feature addition is the addition of an Adjustable Double Disc Anchor option offering 10mm of adjustment. Perfect for installers and enabling variances to the surface being fixed, to be made true, quickly and with ease.
Product Details
- Product
- Edgetec® Double Disc Glass Balustrade
- Category
- Glass Fencing
- Sold by
- Juralco
- Brand
- Edgetec®
- Warranty
- 5 years
Juralco Edgetec® Double Disc Glass Balustrade Anchor is a traditional stainless steel anchor fixing offering from the Edgetec balustrade range - ideal for those seeking a minimalist Frameless Glass Balustrade aesthetic.
Double Disc Anchors are manufactured from solid 316 Marine Grade Stainless Steel. The 30mm long body sets the 12mm - 17.52mm toughened glass panels out from the deck to assist with water draining and cleaning.
The Double Disc Anchor system is ideal for external balconies and stairs - as well as for internal stairs and landings. It can be fixed directly to either timber, steel or concrete surfaces and is finished with a 38mm x 30mm interlinking top rail in a choice of powder coat colours to suit. The finish options are mirror-polished stainless steel with a hidden fixing detail or satin stainless steel with a visible fixing detail.
The latest product feature addition is the addition of an Adjustable Double Disc Anchor option offering 10mm of adjustment. Perfect for installers and enabling variances to the surface being fixed, to be made true, quickly and with ease.
- Specs
Specifications
Edgetec® Double Disc Anchor
- A traditional 50mm diameter disc anchor, fixing panels in place through holes in the glass
- Face fix installation only (fitted to the front of deck face)
- Aluminium disc anchors can be powder coated in a wide range of colours
- Stainless steel disc anchors also available in polished or satin finish
- Available with 12mm or 15mm toughened glass (requires top rail)
- Available in 15.2mm or 17.22mm laminated glass (no top rail required)
- Also available in 13.52mm or 17.52mm Sentry laminated glass (no top rail required)
- Adjustable Double disc anchor available enabling 10mm of variance
- Scope of use
- Occupancy Types A, A Other, B, E, C3 Residential & and B, E & C3 Commercial
- Suitable for pool fencing (fully compliant)
- Toughened safety, laminated and SentryGlas® glass options
- Features
- Enjoy Clear Views
- 12mm - 15mm Toughened Glass
- 15.2 & 17.2 Laminated Safety Glass
- 13.52 & 17.52 Laminated SentryGlas®
- Available in Polished or Satin Marine Grade 316 Stainless Steel
- Adjustable Double disc anchor with 10mm of variance enabled. Offers quicker and easier installation
- Complies with NZS1170 & NZS4223.3.2016
- Suitable for Occupancy Types A, A Other, B, E, C3 Residential and B, E & C3 Commercial
- Performance
- 5-year manufacturers warranty
- 15 or 25 Year Dulux Powder Coating surface finish warranty
Downloads
Downloads (7)7 Direct downloads • 7 Available on request
Frequently asked questions about
Edgetec® Double Disc Glass Balustrade
The Edgetec® Double Disc Glass Balustrade is supplied by Juralco. It is also on their website, and you can browse every product Juralco lists on ArchiPro.
Juralco does not publish a price for the Edgetec® Double Disc Glass Balustrade on ArchiPro. for pricing, or visit their website.
Yes. It is part of the Juralco Double Disc Anchor Balustrade range from Juralco, where you can see every product in the range together.
Yes. It has been specified in projects on ArchiPro, including Summit House by Four Walls Architecture, Coastal Haven by AD Architecture and Cottage Renovation Laingholm by Lynda Slaney Architects. See how it was used in a finished space.
from this page, see their contact details on ArchiPro, or visit their website. The Juralco profile on ArchiPro has the rest of their products.
