Smart Bluetooth Relay Electric Lock
The Smart Bluetooth Relay Electric Lock allows opening electric locks, motorized gates or any electrical actuator which can be activated closing a contact. The Smart Relay closes a contact if a smartphone is registered in the device.
It comes in 2 different models to be selected according to installations requirements: 1. Smart Relay with built-in BLE antenna: the Bluetooth smart antenna is embedded in the Smart Relay box. 2. Smart Relay with Remote BLE antenna: the BLE can be positioned at a distance of 3 meters from the unit.
- CategoryDigital Door Locks, Gate Automation, Car Park Flooring
Functions
The Relay allows controlling electric devices. It is a NO (Normally Open) contact up to 5 Ampere current. The Master switch allows entering in programming mode. This is required the first time from the factory mode. The Master microswitch can be disabled after enrolling, with login enabled, the first smartphone in the users list. Then the smartphone can login without Master and prepare some invitations to login with additional smartphones.
Output
- Can be configured with the Argo App as one of the following:
- Privacy.
- Standard users blocked.
- Passage mode active (office mode).
- Door status.
- Buzzer.
- Green LED or Red LED of Argo devices.
- Lithium battery for Real Time clock Low.
- MASTER mode.
- Alarm for Power Supply low.
- Activates in sequece after RELAY opens eventually controlling the INPUT configured as door status.
- Disabled.
- The OUTPUT relay is a signal relay (1A) and can be also configured as NO (default) or NC by a jumper under the cover enclosure
