Façade Acoustic Double Glazing Systems

Whether you want to improve your building's performance or reduce acoustic transfer through the glass component of your building then Thermosash secondary double glazing could provide the solution.

Performance

Thermal Performance Benefits

The insulative efficiency of an IGU is largely determined by the thickness of the space between the two sheets of glass and whether this space is filled with air or a gas such as argon or krypton. Should the space between be too little, this provides a conductive heat loss between the panes whereas if it is too large, a convective current can begin to circulate causing heat transfer also. Generally, the gap is between 16-19mm. As the separation reduces heat gain or cooling from the transfer of cool surfaces - the technology also works in limiting heat loss from the internal environment.

As one of the largest single running costs of a commercial building is attributed to the conditioning of air (heating or cooling) commercial double glazing can provide significant energy savings to almost any project.

Acoustic Benefits

For optimum acoustic performance of secondary double glazing use a glass which differs in thickness by at least 30%, (e.g. 4mm + 6mm + 10mm). Sound reduction will improve with increased glass thickness (particularly at higher frequencies) due to the greater mass involved.

Increasing the width of cavity produces an increase in sound insulation but not pro rata. Beyond a spacing of about 200mm the incremental acoustic improvement is small and, generally, an expensive unit to install due to typical existing reveal depths. Sound reduction will increase with the use of laminated glass, due to the vibration dampening effect of the PVB or by lining the cavity with sound absorbent insulation material, generating sound reduction of 10db (50%) is generally quite achievable with this product, based on limitations of existing building in conditions.
