Centor S2 Screens

The Centor S2 Insect Screen offers insect protection, fresh air, breezes and uninterrupted views for smaller openings.

Specs

• Frame width – single 25mm jamb: up to 2025mm
• Frame width – single 70mm jamb: up to 2070mm
• Frame width – double: up to 4000mm
• Frame height: up to 4000mm

S2's maximum dimensions are affected by total fabric weight and screen tension. To ensure the product operates well, when the screen is wider the maximum height is reduced, and when the screen is taller the maximum width is reduced. For more information view the S2 frame size limits table which shows the exact limits.

Features

• Operates from any height with one hand so the youngest of family members can operate the screen.
• When not in use, the screen retracts discreetly into the frame removing visual distractions to the view outside whilst also protecting it from damage, dust or dirt. This is especially important for a seasonally used product.
• Centor’s unique load balancing technology allows the screen to glide smoothly across the whole door opening to effortlessly stop at any desired position.
• Compact design – low-profile sill, just 19mm or 25mm high allowing for alignment with the finished floor.
• The durable aluminium frame can be painted in any colour for full personalisation.
• Backed by a 5-year limited warranty.
• For information on the superseded first generation of S2 please visit this page.

Configurations

The S2 and S2Min screens are perfect for smaller openings. They can be fitted to the inside or outside of the opening, so you can maximise inside-outside living to its full potential.

These screens are available in several configurations.

Single

A single screen that extends from either side of the frame and covers the full width of the opening.

Double

Two screens meeting in the middle up of the opening.

XO

A single screen that covers a sliding door opening and stops against the door handle. The second jamb is built into the far wall. OX also available.

Jambless

A single screen that does not have a jamb opposite the screen roll. It provides unimpeded access to handles on sliding doors and windows. It does not block the view through corner fixed-lites.

Insect Mesh

Screen mesh is available in two different weave styles with no pleats or sliding panels to detract from the view:

Standard weave

Keeps insects like moths, flies and mosquitoes outside, while standing the test of time with a durable polyester/PVC mesh construction.

Tight weave

Made from the same durable material as our standard weave but features a smaller aperture to protect homeowners against tiny insects like midges.

Installation

The S2 and S2Min can be specified for new doors or windows, of any brand or composition; it can also be retrofitted to existing doors. Its 19mm or 25mm sill height allows S2 and S2Min to be easily aligned with the finished floor level.

The system can be easily installed on the inside or outside of the opening. Sill drainage holes are provided for systems positioned on the outside to allow water to flow out of the door drainage.
