Centor S4 Insect Screen and Blind

• Frame height
• With insect mesh: 815 - 4000mm
• With exterior blind: 815 - 3200mm
• With interior blind: 815 - 2900mm
• Frame width*
• Single: 1015 - 4611mm
• Combination: 1015 - 4676mm
• Double: 1015 - 9013mm

Multiple factors limit the heights and widths available. Please refer to the S4 frame size limits table, which shows the exact limits.

• Pair with new or existing doors or windows.
• Operates from any height with one hand so the youngest of family members can operate the screen.
• Screen and blind fabrics are held securely in place by top and bottom tabs, preventing screen blow-out – even in a breeze.
• The screen and blind are fully retained within the frame on all sides to allow total control of insects, sunlight and privacy.
• Screen mesh is available in a choice of different weave styles with no pleats or sliding panels to detract from the view.
• Luxury blind fabric is available in light-filtering and blackout with a choice of stylish patterns and a range of colours to suit every home.
• The durable aluminium frame can be powder-coated in any colour for full personalisation.
• Can be mounted on the inside or outside – drainage holes are added to the sill for externally mounted systems.
• Sill cover is quick and easy to remove to make cleaning trouble free.
• Backed by a 5-year limited warranty.

The S4 Screen and Blind complements large sliding and folding doors. It can be fitted to the inside or outside of the opening so you can maximise inside-outside living to its full potential.

Screens and blinds are available in a range configurations:

Single

A single screen or blind that extends from one side of the frame and covers the full width of the opening.

Double

Two screens or blinds (in the same fabric option), which meet at any point along the opening.

Combination

A combination of two fabric types, with one housed in each side of the frame, such as a screen from the left and a blind from the right.

XO

A single screen that covers a sliding door opening and stops against the door handle. The second jamb is built into the far wall. OX also available.

Jambless

A single screen that does not have a jamb opposite the screen roll. It provides unimpeded access to handles on sliding doors and windows. It does not block the view through corner fixed-lites.

Screen mesh is available in a choice of different weave styles with no pleats or sliding panels to detract from the view:

Standard weave

Keeps insects like moths, flies and mosquitoes outside, while standing the test of time with a durable polyester/PVC mesh construction.

Tight weave

Made from the same durable material as our standard weave but features a smaller aperture to protect homeowners against tiny insects like midges.

Exclusively for S4, S5 and S6, luxury blind fabrics available in light-filtering and blockout with a choice of stylish patterns and a range of colours to suit every home.

Light-filtering

This translucent blind material allows natural light inside while protecting from harsh sun and glare during the day and provides homeowners with a degree of privacy in the evening.

Blockout

Our blockout blind is room-darkening, excluding light and providing complete privacy when drawn.

Sun-filtering

Perfect for reducing glare, solar heat gain and fading. Can be fitted internally or externally but a popular choice for outside given its hard-wearing, easy-clean qualities.

All S4 systems fitted to the inside of windows and doors are available in a range of wood veneer finishes.

• Surian Red Cedar
• Rosewood
• Western Red Cedar
• Meranti
• Victorian Ash

S4 can be specified for new doors or windows, of any brand or composition; it can also be retrofitted to existing doors. Its 44mm sill height allows S4 to be easily aligned with finished floor level. The system can be easily installed on the inside or outside of the opening. Sill drainage holes are provided for systems positioned on the outside to allow water to flow out of the door drainage. The drainage holes are not visible and won't block holes in the existing door sill.
