Lockwood Padde Electric Strike
ES200
Electric Strike is intended for door security in commercial & industrial applications with heavy traffic that require access control systems. Suitable for use on hinged doors to work with an extensive range of locks.
Electric Stike Function - replaces a standard door strike and is connected to a power supply. An electric strike's ramped surface can, upon command, pivot out of the way when the lock on the door is in the locked position and the door is opened.
- High-security products are manufactured from stainless steel and designed for use with all access control systems.
- Suitable for use with hinged doors which require either fire or security control as part of a building management system.
- Are flexible and can be changed from fail-safe to fail secure, mounted on the left or right-hand side of the door, and are available in 12 or 24Vdc.
- They offer a strong, dependable, and long-lasting electric strike solution.
Product Details
- Product
- Lockwood Padde Electric Strike 12V Fail Safe Non Monitored ES200
- Category
- Latches and Locks
- Sold by
- Keeler Hardware
- Range
- Lockwood
- Warranty
- 5 years
Keeler Hardware is specified by
Cadence & CoArchitects
R ARCHITECTUREArchitects
Habitat Studio ArchitectsArchitects
Bijl ArchitectureArchitects
Ironbark ArchitectureArchitects
Hive ArchitectureArchitects
Scale ArchitectureArchitects
Bones StudioArchitects
JOST ArchitectsArchitects
De Moyer ArchitectureArchitects
Dieppe DesignArchitects
Anderson ArchitectureArchitects
Alexander &CO.Architects
J Mammone ArchitectureArchitects
mcmahon and nerlichArchitects
TDDP ArchitectsArchitects
Invilla ArchitectureArchitects
David Baillie ArchitectArchitects
Bryant Alsop ArchitectsArchitects
Ha ArchitectureArchitects
Ian Moore ArchitectsArchitects
New SpacesBuilders
Kate NixonInterior Designers
TrueBuild HomesDesign & Build
Susie Miles DesignInterior DesignersDasch AssociatesInterior Designers
Rise Architectural BuildersBuilders
X + OInterior Designers
APC BuildBuilders
STUDIO GAXAInterior Designers
Jumble & StackInterior Designers
Ilm InteriorsJoiners
Schemes & SpacesInterior Designers
Lockwood Padde Electric Strike ES200 Electric Strike is intended for door security in commercial & industrial applications with heavy traffic that require access control systems.
Suitable for use on hinged doors to work with an extensive range of locks.
Electric Stike Function - replaces a standard door strike and is connected to a power supply. An electric strike's ramped surface can, upon command, pivot out of the way when the lock on the door is in the locked position and the door is opened.
- High-security products are manufactured from stainless steel and designed for use with all access control systems.
- Suitable for use with hinged doors which require either fire or security control as part of a building management system.
- Are flexible and can be changed from fail-safe to fail secure, mounted on the left or right-hand side of the door, and are available in 12 or 24Vdc.
- They offer a strong, dependable, and long-lasting electric strike solution.
- Specs
Features:
- Fail-Safe
- Non Monitored
- High security
- 4 Hour fire rating
- 850kg holding force
- 1 million cycles endurance rating
- Cast stainless steel body
- Stainless steel locking pins
- Low Current consumption -
- Max 175mA @12Vdc
- Mounting kit supplied as standard
- 5 Year Tricare Warranty
Applications:
- High traffic areas
- Fire-rated door sets
- Open in/open outdoors
- Suitable for use with all access control systems
Specifications:
- Voltage: 12Vdc
- Current: 175 mA @ 12Vdc - 88mA @ 24Vdc
- Solenoid: Solenoids are rated for continuous use.
- Monitoring: None
- Holding Force: 850kg Static Strength Rating
- Endurance: Cycle tested to 1,000,000 operations
- Latch: Suitable for 15mm latch bolt with 3mm door gap
- Environment: Operational temperature range -20 degree Celcius to +60 degree Celcius
- Body: Solid Stainless Steel Construction
- Keeper: Stainless Steel
Standards and Compliance:
- High security for maximum protection (AS4145.2:1993).
- High durability for maximum frequency usage.
- Successfully fire-rated up to 4hrs on fire door assemblies in accordance with AS1905.1. 2005 (Part 1: Fire resistant door sets)
- Approved to UL1034 (highest level)
- CE Approved
- C-Tick Certified
