Trespa Profix TS20 Facade System - Big River Panels

Profix TS20 Concealed fixed flat panel façade system is a unique aluminium vertical rail system specifically designed for use with Trespa Meteon panels. TS20 offers a cost effective method for fixing Trespa Meteon panels with a vertical set out and up to a maximum height of 4.6 meters.

Profix TS20 is perfect for single storey buildings, parapets and all simple low level construction. Panels are configured vertically with either a ship-lapped vertical joint or an open jointed 10mm negative. Horizontal joints are formed with a simple horizontal shiplap that enables panels to extend to 4.6 meters high.

Panels can be configured to utilise various colours and widths to enhance even the simplest build.

Profix TS20 is compliant and tested to meet the requirements of AS/NZS 4284, NZBC E2/AS1/VM1 and B2 respectively.

As with our other Profix systems TS20 offers architects the design flexibility when combined with our Trespa panel and the extensive range of colours, four different finishes, as well as the impact, UV and graffiti resistance that the Trespa panel provides. Both concealed and exposed fixing options are available.

Talk to Décortech at building concept stage regarding the best panel layout and yield to achieve your design within budget. Décortech will work and co-ordinate with specifiers to provide efficient nesting of panels within master Trespa sheets and tailor a design to the requirements of your project.
