eHaus Pacific
Situated with a commanding view over the popular and growing Foxton Beach community, this architectural version of the barn style genre is a modern take on a timeless simple structure. This building delivers high vaulted ceilings and creates the space to accommodate a large loft space for guests or crafts.
Design Components
Floor: Fully insulated concrete pad with a U-value of 0.182 W/(m²K)
Wall: 140mm timber frame U-value = 0.275 W/(m²K)
Roof: Double layer of fibreglass insulation U-value of 0.145 W/(m²K)
Window Joinery Frame: APL Altherm thermally broken aluminium - Uf value: 4.1 W/(m²K)
Glazing: Double glazed Argon U g-value = 1.12 W/(m²K) g-value = 61%
Ventilation: Zehnder Comfo Air Q350 MHRV
Hot Water: Stiebel Eltron - 220L capacity hot water heat pump
Performance Specs
Total Floor Area: 159 m²
Heating Demand: 34.2 kWh/m²/yr
Heating Load: 20.5 W/m²
Frequency of Overheating: 1.6% year over 25°C
TFA: 132 m²
Form Factor: 3.83
Air Leakage@50Pa: 1 ACH
PER Demand: 50 kWh/m²/yr
