Elevate | Series 600 | Wide Offset 150mm Framing
by Architectural Window Systems
City of Liverpool, Australia
- 394.1K profile views
- 36 saves
Offset 150 x 44mm pocket glazed shopfront framing system designed to complement Series 400 CentreGLAZE™, Series 80 Offset narrow framing and a variety of door systems
Product Details
- Product
- Elevate | Series 600 | Wide Offset 150mm Framing
- Category
- Wall Framing
- Sold by
- Architectural Window Systems
Architectural Window Systems is specified by
Freckle ArchitectureArchitects
DX ArchitectsArchitects
J Mammone ArchitectureArchitects
AO Design StudioArchitects
Kister ArchitectsArchitects
Chan ArchitectureArchitects
Habitat Studio ArchitectsArchitects
Taylor KnightsArchitects
Brcar Morony ArchitectureArchitects
Shane Marsh ArchitectArchitects
BANHAM ArchitectsArchitects
RobertsonCollectifArchitects
Create ArchitectureArchitects
Robert Harwood ArchitectsArchitects
Studio SnellArchitects
Hindley & CoArchitects
ArdelArchitects
Woods BagotArchitects
APC BuildBuilders
Studio UrboBuilding Designers
Gold Leaf ConstructionsBuilders
Seidler GroupDesign & Build
Escea Fireplace CompanyManufacturers and Suppliers
Distinct InnovationsDesign & Build
Design by JonesInterior Designers
Cunningham Custom HomesDesign & Build
Alberse HomesBuilders
Glow DesignBuilding Designers
Millboard DeckingManufacturers and Suppliers
Design by ADBuilding Designers
Alex Urena Design StudioBuilding Designers
Venn ConstructionsBuilders
Centor®Manufacturers and Suppliers
Nadine K DesignBuilding Designers
Reitsma & AssociatesBuilding Designers
Walters MacriPhotographers
KarmatectureBuilding Designers
Offset 150 x 44mm pocket glazed shopfront framing system designed to complement Series 400 CentreGLAZE™, Series 80 Offset narrow framing and a variety of door systems
- Specs
- Glazing pocket designed to be compatible with industry standard but with the added features of a truly captive glazing wedge option and the ability to screw fix door midrails to framing without having to go through the back of the pocket.
- The offset matches 400 CentreGLAZE™ allowing us to use CentreGLAZE™ glazing beads, door stops and awning sash inlay adapters.
- Three 50mm wide door options including fully beaded.
- Three midrail sizes to choose from (50, 115 and 125mm deep).
- Two door thresholds cover both internal and external swing hinged doors.
- Sub-head, sub-sills and two piece sub-jamb to assist with installation.
- Maximum Panel Height *Various
- Maximum Panel Width *Various
- Maximum Glass Thickness ≤ 10.38mm
- SHGC Range 0.25 - 0.75
- Uw Range 4.6 - 6.4
Downloads
Downloads (4)4 Direct downloads • 8 Available on request
Frequently asked questions about
Elevate | Series 600 | Wide Offset 150mm Framing
The Elevate | Series 600 | Wide Offset 150mm Framing is supplied by Architectural Window Systems. It is also on their website, and you can browse every product Architectural Window Systems lists on ArchiPro.
Architectural Window Systems does not publish a price for the Elevate | Series 600 | Wide Offset 150mm Framing on ArchiPro. for pricing, or visit their website.
It is listed under Wall Framing on ArchiPro, where you can compare it with wall framing from other suppliers.
Yes. It is part of the Elevate | Commercial Framing range from Architectural Window Systems, where you can see every product in the range together.
from this page, see their contact details on ArchiPro, or visit their website. The Architectural Window Systems profile on ArchiPro has the rest of their products.
